weBoost's OTR Truck 4G cellular antenna is a classic omnidirectional shaft-mounted design that does not require a ground plane.
This antenna is available separately or kitted with the weBoost Drive 4G-X OTR, Drive X RV or weBoost Sleek OTR cellular boosters.
Specifications
- Model: 304415 (311224 for the Drive X RV OTR)
- Type: Omni-Directional
- Impedance: 50 Ohms
- Cable Type & Length:
- Standard OTR: RG-58 / 14'
- Drive X RV OTR: RG-6 / 25'
- Connector: SMA Male
- Internal Ground Plane: Yes
- Dimensions:
- Standard OTR: 17"
- Drive X RV OTR: 9.5"
- Mounting: 3-way Bracket, spring or rigid base.
- Frequency / Gain:
700-800 Mhz: 2.5 - 3.5 dBi
824 - 894 Mhz: 2.5 - 3.5 dBi
880 - 960 Mhz: 2.5 - 3.5 dBi
1710 - 1880 Mhz: 2.5 - 3.5 dBi
1850 - 1990 Mhz: 2.5 - 3.5 dBi
2110 - 2170 Mhz: 2.5 - 3.5 dBi
2.3 - 2.5 GHz: ?? - Retail Price: $109.99 Retail (Frequently found for ~$70)
Revision Status:
- In summer 2018, weBoost discontinued selling two versions of the trucker OTR antenna and replaced it with a singular kit that provides multiple installation options. The newer version is 17" tall (the former options were 19" and 24") and includes two extension poles and both the rigid & spring mount. The antenna itself remains identical.
- In July 2019, weBoost released the Drive X RV kit which includes the same anteana with a more RV friendly shorter stalk. The kit includes a spring mount and extension pole, with options for 9.5" and 28.5" in total height. This version of the antenna is only available in the Drive X RV kit.
Review & Testing Status
We have had the original 24" rigid version in testing since release in 2016, as well as the 2018 revised OTR kit version. We have tested it extensively in pairing with weBoost and HiBoost boosters, as an independent antenna and using two in a 'mock-MIMO' configuration. It's a solid top performer.
This Antenna is actively in our testing: Here are some more recent rounds of field testing (testing data available to our members):
- Cellular Signal MIMO Antenna Field Testing (Spring 2019)
- Cellular Signal Field Testing – SureCall Fusion2Go 3.0 | weBoost 4G-X OTR | weBoost 4G-M | HiBoost OTR | MIMO Antennas (Late 2018)
- Cellular Signal Field Testing – SureCall Fusion2Go 3.0 | weBoost Connect RV 65 | HiBoost OTR | MIMO Antennas (2nd Quarter 2018)
- Cellular Signal & Embedded Router Field Testing – IBR900 | MAX-BR1 | ConnecT 2.0 | SkyPro LTE | Drive Sleek | MIMO Antennas (1st Quarter 2018)
- Cellular Signal Enhancing Field Testing Results (Mid 2017) - Featuring the new Drive 4G-X RV Kit
Installation Challenge:
In our testing, this antenna shows increased gains over other options - particularly over the 4" magnetic mount antenna and the weBoost 4G-X RV kit.
However, this antenna does present some installation challenges on RVs due to it's height. It was really meant for installing on a semi-trucks rear view mirror - not the roof of an RV.
If you have a rear ladder or retractable batwing antenna on your rig, those do present options that can keep the antenna at a lower profile while in motion. As does using this antenna in a temporary installation on a flagpole/mast or using a suction cup mount.
Some other ideas shared by others include:
- RV Geeks: How To Install The WeBoost Drive 4G-X Cellular Booster & 4G-OTR Antenna (creating a custom roof mount)
- Wheeling It: Easy RV Mod -> The weBoost Drive 4G-X OTR Cellular Booster (temporary attachment to a batwing antenna)
- Drivin' & Vibin': WeBoost OTR 4G-X Cell Booster – Product Review (installation on a small trailer)
- FootPrintDesign - Mobile Internet Cell Signal Booster Install (installation permanently attached to a batwing antenna)
- MIA Member - Custom retracting mount shared by MIA Member Erald in the member forums.
Photo gallery of member installations:
Potential Alternatives to Consider:
For other popular cellular antennas on the market we are tracking - here are our featured options:
Learn More About Selecting Cellular Antennas
This Review Contains Additional Member Exclusive Content
We are honored to be able to present the above overview for free without 3rd party advertising or sponsorships. We are not paid by the manufacturer of this product to provide this listing or review, and nor are we selling this equipment or plan (purchasing links are provided below as a courtesy and some may be affiliates).
Our members have funded this resource center and any extensive hands on time
we have spent with the product to review it.
The in-depth portions of this review are made available to them which might contain: hands on testing notes, field testing data, user interface tour, product analysis, comparison to alternatives, setup tips, video tutorial, insider tips, vendor discounts and fellow member experiences.
If you're a member, please log in to continue with this review.
If you're not a member.. please consider joining us!
Purchasing Options
weBoost | Repeater Store | WilsonAmplifiers | 5GStore
LivinLite.Net (also available with SMB Adapter for use with Drive Reach & Sleek)
