The Panorama Wideband MIMO brings the potential benefits of MIMO diversity to an outdoor pole-mounted antenna.
It comes in directional and omnidirectional options in similar form factors.
Product Variations
Directional Antennas
Specifications
- Models:
- WMM8G-7-38-5SP
- WMM8G-7-38-03NJ
- Form Factor: Panel
- Direction: Directional
- # of Antenna Elements: 2x2 MIMO
- Frequency Range: 698MHz - 3800MHz
- Impedance: 50 ohms
- Cable Type & Length:
- WMM8G-7-38-5SP: CS29, 2 x 16'
- WMM8G-7-38-03NJ: CS29, 2 x 12"
- Connector:
- WMM8G-7-38-5SP: 2x SMA-Male (most common RV connection)
- WMM8G-7-38-03NJ: 2x F-Female
- Dimensions (H x L x W): 9 x 7.1 x 3.7 inches
- Weight: 2.2 pounds
- Mounting Options: Wall or Pole Bracket
- Outdoor Rated: Yes
- Frequency Range/Gain:
- 698 - 960 MHz: 6 dBi
- 1710 - 2170 MHz: 9 dBi
- 2396 - 2700 MHz: 9 dBi
- 3400 - 3800 MHz: 9 dBi
- Special Features/Notes: Not Specified
- Retail Price:
- WMM8G-7-38-5SP: $158.76
- WMM8G-7-38-03NJ: $216.00
Omnidirectional Antennas
Specifications
- Models:
- WMMG-7-38-5SP
- WMMG-7-38-03NJ
- Form Factor: Panel
- Direction: Omnidirectional
- # of Antenna Elements: 2x2 MIMO
- Frequency Range: 698MHz - 3800 MHz
- Impedance: 50 ohms
- Cable Type & Length:
- WMMG-7-38-5SP: 2x 16' CS29
- WMMG-7-38-03NJ: 2x 1' CS29
- Connector:
- WMMG-7-38-5SP: 2x SMA-Male (most common RV connection)
- WMMG-7-38-03NJ: 2x N-Female
- Dimensions (H x L x W): 6.1 x 6.1 inches
- Weight:
- WMMG-7-38-5SP: 2.1 pounds
- WMMG-7-38-03NJ: 1 pound
- Mounting Options: Wall or Pole Bracket
- Outdoor Rated: Yes
- Frequency Range/Gain:
- 698 - 960 MHz: 2 dBi
- 1710 - 2700 MHz: 5 dBi
- 3400 - 3800 MHz: 4 dBi
- Special Features/Notes: Not Specified
- Retail Price:
- WMMG-7-38-5SP: $153.60
- WMMG-7-38-03NJ: $192.00
